MUL30EP Super Low Pit Lift
The MUL30EP is a compact, pit-installed scissor lift offering a low-profile design with a 3,000 kg lifting capacity. It’s engineered for workshops needing a flush-floor finish while maintaining the ease of operation via push-button controls, making it perfect for passenger cars and compact service bays.
MUL30EP Super Low Pit Lift
Sale price$27,390.00 AUD
SCCIS
Low to the ground, high on performance—Bishamon MUCROSS lifts deliver maximum access in minimal space
View Datasheet
MUS40UL Multi Power Pit Lift
Sale price$40,590.00 AUD
MUL30EP Super Low Pit Lift
Sale price$27,390.00 AUD
MUS40UL Multi Power Pit Lift
Sale price$40,590.00 AUD
MUL30EP Super Low Pit Lift
Sale price$27,390.00 AUD
Installation
Pit
Pit
Lower Lift Capacity
4,000 kg
3,000 kg
Upper Lift Capacity
3,000 kg
-
Drive-on Plate Length
4,500 mm
4,000 mm
Control
Cable remote control switch
Push-button switch
Power
3-phase
3-phase
Motor
2.2 kW
1.5 kW
Lifting Time (60Hz)
Lower: 60 sec / Upper: 8 sec
65 sec
Lifting Time (50Hz)
Lower: 72 sec / Upper: 10 sec
78 sec
Lowering Time (approx)
35 sec (Lower) / 10 sec (Upper)
31 sec
Applicable Wheelbase Max
3,800 mm
1,570 mm
Oil Volume
18L (ISO VG32)
18L (ISO VG32)
Air Pressure
0.7 – 1.0 MPa
0.5–1.0 MPa
